| Hardware Specification |
| Interface |
"Data" Input Ports: 24 x RJ-45 STP
"PoE (Data+Power)" Output Ports: 24 x RJ-45 STP
Management Port: 1 x RJ-45; 10/100Base-TX, auto-negotiation, auto-MDI / MDIX |
| LED |
System: Power x 1 (Green)
Management Port x 2: 10/100 (Green / Orange)
Per PoE Port: PoE in Use x 1 (Green)
|
| Network Cable |
10Base-T: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328ft)
100Base-TX: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328ft)
EIA/TIA- 568 100-ohm STP (100m)
|
| Dimension (W x D x H) |
440 x 200 x 44 mm (1U height) |
| Weight |
3.3kg |
| Power Requirement |
100-240V AC, 50/60 Hz |
| Power Consumption |
400 watts max. |
| Operating Temperature |
0 ~ 50 Degree C |
| Storage Temperature |
-40 ~ 70 Degree C |
| Humidity |
5 ~ 95% (Non-condensing) |
| Cooling |
Fan x 2 |
| Power over Ethernet |
| PoE Standard |
IEEE 802.3af Power over Ethernet / Mid-Span PSE |
| PoE Power supply Type |
Mid-Span |
| PoE Power Output |
Per Port DC 48V 15.4 watts |
| Power Pin Assignment |
4/5(+), 7/8(-) |
| PoE Power Budget |
380 Watts |
| Management |
| Management Interface |
Web, PLANET Smart Discovery Lite |
| PoE Management |
Power Limit by Priority and Total Limit
Per port power enable/disable
Power feeding priority
Current usage and status
Total power consumption
|
| Management Feature |
System / Management functions setup
Web firmware upgrade
SNMP Trap for alarm notification of events
|
| Standards Conformance |
| Standards Compliance |
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3af Power over Ethernet
|
| Regulation Compliance |
FCC Part 15 Class A, CE |
