| Video Specification |
| Horizontal Resolution |
540 TV Lines |
| Scanning System |
NTSC / PAL |
| Effective Pixels |
NTSC 380K: 768 (H) x 494 (V)
PAL 440K: 752 (H) x 582 (V)
|
| Sensor |
1/4" Color Sony CCD |
| Lens Type |
36X optical zoom, 12X digital zoom |
| View Angle |
H: 1.8 ~ 60.8 Degree / V: 1.3 ~ 43 Degree |
| Lens |
F1.6~3.4/ F1.6 ~ 122.4 mm |
| S/N Ratio |
> 50 dB (AGC Off) |
| Minimum Illumination |
0.1 lux , 0.01lux(B/W) |
| Focal Length |
3.4~122.4 mm |
| Focus Mode |
Auto / Manual |
| White Balance |
Auto / Manual |
| Iris Control |
Auto / Manual |
| Electronic Shutter |
1/1~1/10k sec. |
| AGC control |
Auto / Manual |
| Back Light Compensation |
On/Off |
| Image (Video Setting) |
| Video Encoder |
H.264 / M-JPEG simultaneously |
| Video Resolution |
D1: NTSC 720x480 / PAL 720x576
CIF: NTSC 352x240 / 352x288
|
| Frame Rate |
30fps for all resolutions |
| Audio Compression |
G.726 ADPCM / AAC |
| Alarm Reaction |
Preset, Sequence, Auto pan, Cruise |
| Network and Configuration |
| Network Interface |
Ethernet 10Base-T/100Base-TX |
| Networking Protocol |
TCP/UDP/IP, HTTP, FTP, SMTP, ARP, ICMP, DHCP, Telnet, RTP/RTSP |
| Browser / Software |
Microsoft ® Internet Explorer 6.0 or later, Cam Viewer Plus Lite/Pro |
| Hardware |
| Pan Degree |
0 ~ 360 Degree continuous panning |
| Tilt Degree |
90 Degree with instant flip |
| Preset Point |
256 present points |
| Camera Cruise |
8 cruises |
| Audio in / Audio out |
1 x MIC in / 1 x Line out |
| Video Output |
1.0 Vp-p / 75ohm (BNC connector) |
| 2-Way Audio |
Full-duplex, Half-duplex, Simplex |
| DI / DO ports |
DI x 4 / DO x 1 (dry contact) |
| Protection Class |
IP-66 outdoor classification, Built-in Fan and Heater |
| Dimension |
Φ190 x 302.5 mm |
| Weight |
2.6kg |
| Power Supply |
AC 24V ± 10%, 3A |
| Operating Temperature |
-45 ~ 50 Degree C |
| Operating Humidity |
20 – 90% (non- condensing) |
| Power Consumption |
65 W (with Heater) |
| Emission |
CE, FCC |
