| General |
| Image sensor |
1/3" Sony EXview HAD CCD II |
| Effective Pixels |
NTSC: 976 x 494
PAL: 976 x 582
|
| Horizontal Resolution |
Color : 650 TVL
B / W : 700 TVL
|
| Lens |
Board Lens 3.6mm |
| Min. Illuminator |
0.01 Lux (30IRE@F2.0) Day Mode |
| Auto Electronic Shutter |
NTSC:1/60s~1/100,000s
PAL:1/50s~1/100,000s
|
| S/N Ratio |
More than 48 dB |
| Gamma Characteristic |
0.45 |
| White Balance |
Auto / Indoor / Outdoor / Manual / Push Auto |
| Gain Control |
Auto |
| Flickless Mode |
On / Off ( NT:1/100, PA: 1/120 ) |
| Back Light Comp. |
On / Off |
| Synchronous System |
Internal |
| Video Output |
Composite 1.0 Vp-p, 75 ohm |
| IR LED |
24 pieces |
| IR Wavelength |
850 nm |
| IR Distance |
20~25 meters |
| Vandal Resistance |
10 pounds |
| Water Resistance |
IP66 |
| Environment |
| Power Requirement |
DC 12V
IR on: 380mA max./IR
|
| Dimension (Φ x H) |
145 x 110 mm |
| Weight |
1.03 Kg |
| Operating Temperature |
-10 ~ 50 Degree C |
