| Hardware Specification |
| Copper |
Ports
4 x 10/100Base-TX, Auto-negotiation, Auto-MDI / MDI-X
Cable
10Base-T : 2-pair UTP Cat. 3, 4, 5 cable (100meters, max.)
100Base-TX : 2-pair UTP Cat. 5 cable (100meters, max.) |
| Optical |
Port
1 x 100Base-FX
Cable
ISW-511T: 50/125μm / 62.5/125μm fiber
ISW-511TS15: 9/125μm fiber
Mode
ISW-511T: Multi-mode
ISW-511TS15: Single-mode
Distance
ISW-511T: 2km
ISW-511TS15: 15km
Frequency
ISW-511T: 1310nm
ISW-511TS15: 1310nm
Launch Power
ISW-511T: Max. -14dBm, Min. -20dBm
ISW-511TS15: Max. 0dBm, Min. -20dBm
Receive Sensitivity
ISW-511T: -32dBm
ISW-511TS15: -32dBm
Max. Input Power
ISW-511T: -14dBm
ISW-511TS15: 0dBm |
| Dimension (W x D x H) |
135 x 97 x 32 mm |
| Weight |
436g |
| Power Requirement |
12~48V DC
Redundant power with polarity reverse protection function
|
| Power Consumption / Dissipation |
13.7 Watts / 46 BTU |
| Installation |
DIN Rail Kit and Wall Mount Ear |
| Alarm |
Provides one relay output for power fail
Alarm Relay current carry ability: 1A @ DC 24V
|
| Switch Specification |
| Switch Processing Scheme |
Store-and-Forward |
| Address Table |
2K entries |
| Buffer |
1Mbit |
| Flow Control |
Back pressure for half duplex,
IEEE 802.3x Pause Frame for full duplex
|
| Switch Fabric |
1Gbps |
| Throughput (Packet Per Second) |
0.74Mpps @ 64Bytes
|
| Standards Conformance |
| Standards Compliance |
IEEE 802.3 Ethernet, 10Base-T
IEEE 802.3u Fast Ethernet, 100Base-TX, 100Base-FX
IEEE 802.3x Full-duplex flow control
|
| Temperature |
Operating: -40~75 Degree C
Storage: -40~85 Degree C
|
| Humidity Operating |
Operating: 5~90%
Storage: 5~90% (Non-condensing) |
| Regulation Compliance |
FCC Part 15 Class A, CE |
| Stability Testing |
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
|
