| Hardware Specification |
| 10/100Base-TX Port |
1 RJ-45 Auto-MDI/MDI-X port |
| 100Base-FX Port |
IFT-802T:1 SC Interface
IFT-802TS15:1 SC Interface
IFT-805AT:1 SFP Slot |
| Fiber Port Type |
IFT-802T:SC / Multi-mode
IFT-802TS15:SC / Single-mode
IFT-805AT:Vary on module |
| Cable Distance |
IFT-802T:2km
IFT-802TS15:15km
IFT-805AT:Vary on module |
| Optical Frequency |
IFT-802T:1310nm
IFT-802TS15:1310nm
IFT-805AT:Vary on module |
| Launch Power (dBm) |
Max
IFT-802T:-14
IFT-802TS15:0
Min
IFT-802T:-20
IFT-802TS15:-20
Vary on module
IFT-805AT |
| Receive Sensitivity (dBm) |
IFT-802T:-32
IFT-802TS15:-32
IFT-805AT:Vary on module |
| Maximum Input Power (dBm) |
IFT-802T:-14
IFT-802TS15:0
IFT-805AT:Vary on module |
| Dimension (W x D x H) |
135 x 85 x 32 mm |
| Weight |
430g |
| Installation |
DIN rail kit and wall mount ear |
| Maximum Frame Size |
1522bytes packet size |
| Flow Control |
Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex |
| Enclosure |
IP-30 Slim Type Metal Case |
| LED Indicator |
System:
•Power 1 (Green)
•Power 2 (Green)
•Fault (Green)
1x copper port:
•10/100 (Green)
•LNK/ACT (Green)
1 x 100FX port:
•100 (Green)
•LNK/ACT (Green) |
| Power Input |
12 to 48V DC Redundant power with polarity reverse protection function |
| Power Consumption |
3 Watts/ 10BTU (maximum) |
| Protection |
ESD (Ethernet): 6KV DC
Surge (Power): 6KV DC
|
| Speed |
Twisted-pair:
•10/20Mbps for Half / Full-Duplex
•100/200Mbps for Half / Full Duplex
Fiber-optic:
•200Mbps for Full-Duplex
|
| Network cables |
10/100Base-TX:
•2-Pair UTP Cat. 3, 4, 5 (100meters, max.)
•EIA/TIA-568 100-ohm STP (100meters, max.)
100Base-FX:
•IFT-802T: Multi-mode optic fiber 62.5/125μm / 50/125μm (2km)
•IFT-802TS15: Single-mode optic fiber 9/125μm (15km)
•IFT-805AT: SFP Slot (Depends on SFP module)
|
| Standards Conformance |
| Emissions |
FCC Class A, CE Class A |
| Standards Compliance |
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX / 100Base-FX
IEEE 802.3x Flow Control and Back pressure
|
| Stability Testing |
IEC60068-2-32 (Free fall)
IEC60068-2-27 (Shock)
IEC60068-2-6 (Vibration)
|
| Environment |
| Operating Temperature |
-40~75 Degree C |
| Operating Humidity |
5~90% non-condensing |
| Storage Temperature |
-40~85 Degree C |
| Storage Humidity |
5~90% non-condensing |
